Product ID: | XNT-HDMI001151 |
product name: | HDMI D TYPE Motherboard 0.90 Enclosure DIP |
specification: | Plastic: Black high temperature UL94V-0; Terminal: Copper alloy |
Product Note: | D type female, sink type L7.70*W6.20* sink 0.90 |
Product Category: | HDMI series |
Technical parameters:
1. Rated current: 0.3A
2. Rated voltage: 40V
3. Operating temperature: -20 °C ~ +85 °C
4. Storage temperature: -20 °C ~ +85 °C
5. Contact resistance: 10m ohms max.
6 Insulation resistance: Single test: 100M ohms min./500VDC Matching male: 10M ohms min./150VDC
7. Durability: 5000 times
8. Product temperature: 260±5°C 10S
9. RoHS Compliant
:
1. This connector is widely used in mobile phones, tablet PCs, navigators, LCD TVs, etc.;
2. This product inspection process is: IQC feed inspection -> storage -> pre-line self-test -> IPQC inspection - -> FQC final inspection -> OQC cargo inspection
3. This product production process is: pre-line inspection -> automatic machine molding -> assembled shell -> electrical test -> pressure test -> Flatness test -> Positive test -> Appearance test -> FQC test -> Check in
